BRAKE SYSTEM 13
139
A00634-11
–
Detach spring
1
.
–
Release nut
2
and use screw
3
to adjust the specified free
travel
A
.
Guideline
Free travel at foot brake lever 3 … 5 mm (0.12 … 0.2 in)
Info
The range of adjustment is limited.
–
Hold screw
3
and tighten nut
2
.
–
Attach spring
1
.
