14 WHEELS, TIRES
144
S00674-10
Main work
–
Remove screw
1
and pull wheel speed sensor
2
out of the
hole.
–
Remove nut
3
and washer.
–
Remove chain adjuster
4
.
–
Holding the rear wheel, withdraw wheel spindle
5
with the
washer and chain adjuster
4
.
– Push the rear wheel forward as far as possible and take the
chain off the rear sprocket.
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Pull the rear wheel back and take it out of the link fork.
Info
Do not operate the foot brake lever when the rear wheel
is removed.
