WHEELS, TIRES 14
149
S00678-10
– Lay the rear wheel on a workbench with the rear sprocket fac-
ing upward and insert the wheel spindle in the hub.
–
To check play
A
, hold the rear wheel tight and try to rotate
the rear sprocket.
Info
Measure the play on the outside of the rear sprocket.
Play of damping rubber
pieces on rear wheel
≤ 5 mm (≤ 0.2 in)
»
If clearance
A
is larger than the specified value:
– Change all the damping rubber pieces of the rear hub.
Finishing work
– Install the rear wheel. ( p. 145)
– Remove the rear of the motorcycle from the lifting gear.
( p. 103)
– Check the chain tension. ( p. 114)
