KTM 250 DUKE User Manual

6 CONTROLS 25
6.7 Turn signal switch
M00706-11
The turn signal switch

is fitted on the left side of the handlebar.
Possible states
Turn signal off
Turn signal, left, on – Turn signal switch pressed to the left. The turn signal
switch returns automatically to the central position after use.
Turn signal, right, on – Turn signal switch pressed to the right. The turn
signal switch returns automatically to the central position after use.
To switch off the turn signal, press the turn signal switch towards the switch case.
6.8 Emergency OFF switch
M00707-11
The emergency OFF switch

is fitted on the right side of the handlebar.
Possible states
Emergency OFF switch off – In this position, the ignition circuit is
interrupted, a running engine stops, and a non-running engine cannot be
started.
Emergency OFF switch on – This position is required for operation; the igni-
tion circuit is closed.

KTM 250 DUKE Specifications

General

Engine Type	1-cylinder, 4-stroke engine
Displacement	248.8 cc
Max Torque	24 Nm @ 7, 500 rpm
Transmission	6-speed
Cooling System	Liquid cooled
Rear Suspension	WP monoshock
Seat Height	830 mm
Dry Weight	149 kg
Bore x Stroke	72 mm x 61.1 mm
Compression Ratio	12.5:1
Ground Clearance	185 mm
Max Power	22.1 kW (30 hp) @ 9, 000 rpm
Fuel System	Bosch Electronic Fuel Injection (EFI)
Front Suspension	WP upside-down fork
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating caliper, brake disc
Fuel Tank Capacity	13.4 l
Frame	Steel trellis frame
