KTM 250 DUKE User Manual

6 CONTROLS 34
6.13.5 Indicator lamps
401686-01
Possible states
The turn signal indicator light flashes green simultaneously with the turn
signal – The turn signal is switched on.
The engine diagnosis warning lamp (MIL) lights up red – The OBD (on-
board diagnosis) has detected an emission- or safety-critical error.
The shift warning lights up/flashes red – The set shift speed has been
reached.
The idling speed indicator lamp lights up green – The transmission is
shifted to idle.
The high beam indicator lamp lights up blue – The high beam is switched
on.
The immobilizer indicator lamp lights up or flashes red – Status or error
message for immobilizer/alarm system (optional).
The general warning lamp lights up yellow – An operating safety (warning)
message was detected. This is also shown in the info display.
ABS warning lamp lights up/flashes yellow – Status or error messages relat-
ing to ABS (antilock brake system).

KTM 250 DUKE Specifications

General

Engine Type	1-cylinder, 4-stroke engine
Displacement	248.8 cc
Max Torque	24 Nm @ 7, 500 rpm
Transmission	6-speed
Cooling System	Liquid cooled
Rear Suspension	WP monoshock
Seat Height	830 mm
Dry Weight	149 kg
Bore x Stroke	72 mm x 61.1 mm
Compression Ratio	12.5:1
Ground Clearance	185 mm
Max Power	22.1 kW (30 hp) @ 9, 000 rpm
Fuel System	Bosch Electronic Fuel Injection (EFI)
Front Suspension	WP upside-down fork
Front Brake	Four-piston radial fixed caliper, brake disc
Rear Brake	Single-piston floating caliper, brake disc
Fuel Tank Capacity	13.4 l
Frame	Steel trellis frame
