KTM 390 DUKE 2021 User Manual

9 RIDING INSTRUCTIONS
100
– If the engine stalls (e.g. at an intersection), just pull the clutch
lever and actuate the start button. The transmission must not
be shifted into neutral.
– If the oil pressure warning lamp lights up during a trip, stop
as soon as it is safe to do so and switch off the engine. Contact
an authorized KTM workshop.
– If the malfunction indicator lamp lights up during a trip,
please contact an authorized KTM workshop as soon as possi-
ble.
– If the general warning lamp lights up during a trip, an oper-
ating safety (warning) message was detected.
Info
All warnings which have occurred are displayed and
stored in the Warning menu until these are no longer
active.
9.5 Applying the brakes
Warning
Danger of accidents Moisture and dirt impair the brake system.
– Brake carefully several times to dry out and remove dirt from the brake linings and the brake discs.

KTM 390 DUKE 2021 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Cooling System	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP APEX Monoshock
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Wheelbase	1, 357 mm
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Instrumentation	TFT display
Headlight	LED
Tail Light	LED
Power	32 kW (44 hp) @ 9, 000 rpm
Fuel System	Electronic Fuel Injection
Front Suspension	WP Apex 43 mm
Rear Brake	Single-piston floating caliper, brake disc
ABS	Bosch 9.1MP Two Channel ABS (Supermoto ABS)
Fuel Tank Capacity	13.4 l
Engine Type	Single-cylinder, 4-stroke, liquid-cooled
Front Brake	Four-piston radial fixed caliper, brake disc
