KTM 390 DUKE 2021 User Manual

7 COMBINATION INSTRUMENT
42
7.1 Combination instrument
M01577-10
The combination instrument is attached in front of the handlebar.
The combination instrument is divided into two function areas.
1
indicator lamps ( p. 46)
Display
2
7.2 Activation and test
F00876-01
Activation
The combination instrument is activated when the ignition is
switched on.
Info
The brightness of the displays is controlled by an ambient
light sensor in the combination instrument.
Test
The welcome text appears on the display and the indicator lamps
are briefly activated for a function check.

KTM 390 DUKE 2021 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	37 Nm @ 7, 000 rpm
Transmission	6-speed
Cooling System	Liquid cooled
Frame	Steel trellis frame, powder coated
Rear Suspension	WP APEX Monoshock
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Wheelbase	1, 357 mm
Seat Height	830 mm
Ground Clearance	185 mm
Dry Weight	149 kg
Instrumentation	TFT display
Headlight	LED
Tail Light	LED
Power	32 kW (44 hp) @ 9, 000 rpm
Fuel System	Electronic Fuel Injection
Front Suspension	WP Apex 43 mm
Rear Brake	Single-piston floating caliper, brake disc
ABS	Bosch 9.1MP Two Channel ABS (Supermoto ABS)
Fuel Tank Capacity	13.4 l
Engine Type	Single-cylinder, 4-stroke, liquid-cooled
Front Brake	Four-piston radial fixed caliper, brake disc
