ELECTRICAL SYSTEM 15
177
M00729-10
Main work
– Connect a battery charger to the 12-V battery. Switch on the
battery charger.
Battery charger (58429074000)
In addition, this battery charger can be used to test the open-
circuit voltage, the starting ability of the 12-V battery, and
the alternator. It is impossible to overcharge the 12-V battery
using this device.
Info
Never remove cover
1
.
Charge the 12-V battery to a maximum of 10 % of the
capacity specified on battery housing
2
.
– Switch off the battery charger after charging and disconnect
from the 12-V battery.
Guideline
The charging current, charging voltage, and charging time
must not be exceeded.
Recharge the 12-V battery
regularly when the motorcy-
cle is not being used
3 months
– Position the negative cable and mount and tighten the screw.
– Position the negative terminal cover.
