TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 11

Spoke nipple, front wheel M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –

Screw, spoiler on fuel tank

(XC‑W SIX DAYS, EXC USA)

M5x12 1.5 Nm (1.11 lbf ft) –

Spoke nipple, rear wheel M5 5… 6 Nm (3.7… 4.4 lbf ft) –

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) –

Screw, chain sliding guard M6 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, shock absorber adjusting ring M6 5 Nm (3.7 lbf ft) –

Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)

Loctite

2701

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp (EXC USA,

all SIX DAYS models)

M8 12 Nm (8.9 lbf ft) –

Screw, bottom triple clamp

(EXC EU/AUS)

M8 15 Nm (11.1 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, engine brace M8 33 Nm (24.3 lbf ft) –

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, side stand fixing M8 40 Nm (29.5 lbf ft)

Loctite

2701

Screw, subframe M8 35 Nm (25.8 lbf ft)

Loctite

2701

Screw, top steering stem (EXC USA, all

SIX DAYS models)

M8 17 Nm (12.5 lbf ft)

Loctite

243™

Screw, top steering stem

(EXC EU/AUS)

M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp (EXC USA, all

SIX DAYS models)

M8 17 Nm (12.5 lbf ft) –

Screw, top triple clamp (EXC EU/AUS) M8 20 Nm (14.8 lbf ft) –

Engine attachment bolt M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 50 Nm (36.9 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft)

Loctite

243™

Screw, bottom shock absorber M12 80 Nm (59 lbf ft)

Loctite

2701

Screw, top shock absorber M12 80 Nm (59 lbf ft)

Loctite

2701

Nut, seat fixing M12x1 20 Nm (14.8 lbf ft) –

Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –

Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –

Screw, bottom steering head

(XC‑W SIX DAYS)

M20x1.5 60 Nm (44.3 lbf ft)

Loctite

243™

Screw, top steering head M20x1.5 10 Nm (7.4 lbf ft) –

Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft)

Loctite

243™

Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft) –
