3 WORK 13
3.9 Installing the front wheel
Warning
Danger of accidents Reduced braking efficiency due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
K00084-10
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change the front wheel bearing. ( p. 13)
–
Clean and grease shaft seal rings
and bearing surface
of the spacers.
Long-life grease ( p. 28)
– Insert the spacers.
– Position the front wheel and insert the wheel spindle.
The brake linings are correctly positioned.
M01022-10
(EXC Six Days)
–
Align the brake disc guard so that gaps
and
are the same size.
K00082-11
–
Mount and tighten screw
.
Guideline
Screw, front wheel spindle M20x1.5 35 Nm
(25.8 lbf ft)
– Activate the hand brake lever multiple times until the brake linings are in contact
with the brake disc.
– Remove the motorcycle from the lift stand. ( p. 8)
– Pull the front wheel brake and push down hard on the fork several times to align
the fork legs.
–
Fully tighten screw
.
Guideline
Screw, fork stub M8 15 Nm
(11.1 lbf ft)
3.10 Changing the front wheel bearing
Preparatory work
– Raise the motorcycle with the lift stand. ( p. 8)
– Remove the front wheel. ( p. 12)
B03356-10
Main work
–
Remove shaft seal rings
and
.
