CARBURE
TOR
17
115
R00566-11
–
Mount
the
carburetor.
–
Mount
the
engine
breather
hose
and
position
clamp
3
.
R04489-11
–
Mount
the
inlet
sleeve.
–
Position
and
tighten
hose
clip
4
.
–
Position
and
tighten
hose
clip
5
.
R00564-11
–
Mount
fuel
hose
6
.
Finishing
work
–
Check
the
throttle
cable
play.
(
p.
98)
–
Carburetor
-
adjust
the
idle
speed.
(
p.
100)
116
118
