22 TECHNICAL DATA 179

Screw, side stand switch EJOT 2 Nm (1.5 lbf ft) –

Screw, SLS valve EJOT 2 Nm (1.5 lbf ft) –

Fitting, side stand switch M4 2 Nm (1.5 lbf ft) –

Spoke nipple, front wheel M4.5 4 Nm (3 lbf ft) –

Spoke nipple, rear wheel M4.5 4 Nm (3 lbf ft) –

Bolt, foot brake lever stub M5 6 Nm (4.4 lbf ft) Loctite

243™

Remaining nuts, chassis M5 4 Nm (3 lbf ft) –

Remaining screws, chassis M5 4 Nm (3 lbf ft) –

Screw, brake line holder on swingarm M5 4 Nm (3 lbf ft) –

Screw, cable on starter motor M5 3 Nm (2.2 lbf ft) –

Screw, combination switch, left M5 3.5 Nm (2.58 lbf ft) –

Screw, electrical holder M5 3 Nm (2.2 lbf ft) –

Screw, exhaust heat shield M5 8 Nm (5.9 lbf ft) Loctite

243™

Screw, fuel hose clamp on fuel tank M5 5 Nm (3.7 lbf ft) –

Screw, fuel level sensor M5 3 Nm (2.2 lbf ft) –

Screw, fuel pump M5 4 Nm (3 lbf ft) –

Screw, fuel tank closure flange M5 2.5 Nm (1.84 lbf ft) –

Screw, headlight mask M5 5 Nm (3.7 lbf ft) –

Screw, pressure regulator M5 4 Nm (3 lbf ft) –

Screw, throttle grip M5 3.5 Nm (2.58 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws on fuel tank M6 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –

Screw connection, foot brake cylinder M6 10 Nm (7.4 lbf ft) –

Screw, ABS control unit M6 5 Nm (3.7 lbf ft) –
