11 SERVICE WORK ON THE CHASSIS
52
11.15 Installing the start number plate
V00829-10
– Attach the start number plate to the brake line.
– Position the start number plate.
Holding lugs
1
engage in the fender.
V00828-10
–
Mount and tighten screw
2
.
Guideline
Start number plate
screw
M6 4 Nm (3 lbf ft)
11.16 Removing front fender
Preparatory work
– Remove the start number plate. ( p. 51)
V00830-10
Main work
–
Remove screws
1
.
–
Remove screws
2
. Take off the front fender.
11.17 Installing front fender
V00831-10
Main work
– Position front fender.
–
Mount and tighten screws
1
.
Guideline
Screw, front fender M6 6 Nm (4.4 lbf ft)
–
Mount and tighten screws
2
.
Guideline
Screw, front fender M6 6 Nm (4.4 lbf ft)
Finishing work
– Install the start number plate. ( p. 52)
