TECHNICAL DATA 23
127
Screw, locking lever M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, main shaft bearing support M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil pan M6x30 10 Nm (7.4 lbf ft)
Screw, oil pan M6x35 10 Nm (7.4 lbf ft)
Screw, oil pump cover M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil pump unit M6 10 Nm (7.4 lbf ft)
Screw, oil/water heat exchanger M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, shift shaft retaining bracket M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, stator M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, timing chain shaft M6 10 Nm (7.4 lbf ft)
Screw, upper guide rail M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, valve cover M6 10 Nm (7.4 lbf ft)
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, water pump wheel M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Nut, exhaust flange M8 15 Nm (11.1 lbf ft)
Copper paste
Oil nozzle for clutch lubrication M8 5 Nm (3.7 lbf ft)
Loctite
®
243™
Remaining screws for engine M8 20 Nm (14.8 lbf ft)
Screw plug, locking screw M8 15 Nm (11.1 lbf ft)
Screw, engine case M8x45 25 Nm (18.4 lbf ft)
Screw support greased
Screw, engine case M8x55 25 Nm (18.4 lbf ft)
Screw support greased
Screw, engine case M8x65 25 Nm (18.4 lbf ft)
Screw support greased
Screw, engine case M8x90 25 Nm (18.4 lbf ft)
Screw support greased
Screw, knock sensor M8 20 Nm (14.8 lbf ft)
Screw, oil pump idler gear M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, tensioning rail M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Stud, exhaust flange M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
