4 TECHNICAL DATA 13

4.1 Chassis tightening torques

Screw, combination switch, left M4 2 Nm (1.5 lbf ft) –

Screw, side stand switch M4 2 Nm (1.5 lbf ft) –

Rear fairing screw M5x12 3.5 Nm (2.58 lbf ft) –

Rear fairing screw M5x17 3.5 Nm (2.58 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw brake line holder on frame M5 2 Nm (1.5 lbf ft) –

Screw, brake line holder on swingarm M5 5 Nm (3.7 lbf ft) –

Screw, cable channel M5 5 Nm (3.7 lbf ft) –

Screw, cable guide, wheel speed sen-

sor, rear

M5 3 Nm (2.2 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, combination switch, right M5 3.5 Nm (2.58 lbf ft) –

Screw, cover part M5 3.5 Nm (2.58 lbf ft) –

Screw, filler cap M5 3 Nm (2.2 lbf ft) –

Screw, foot brake lever stub M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, fuel level sensor M5 3 Nm (2.2 lbf ft) –

Screw, heat guard on main silencer M5 4 Nm (3 lbf ft) –

Screw, wind shield M5 3.5 Nm (2.58 lbf ft) –

Ground fitting on frame M6 6 Nm (4.4 lbf ft) –

Hand guard fitting M6 6 Nm (4.4 lbf ft) –

Nut, ABS unit fixation M6 8 Nm (5.9 lbf ft) –

Remaining chassis nuts M6 10 Nm (7.4 lbf ft) –

Remaining chassis screws M6 10 Nm (7.4 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, battery terminal M6 4.5 Nm (3.32 lbf ft) –

Screw, brake line holder on bottom

triple clamp

M6 10 Nm (7.4 lbf ft) –

Screw, cable channel M6 5 Nm (3.7 lbf ft) –

Screw, chain guide M6 5 Nm (3.7 lbf ft) –

Screw, clutch assembly M6 5 Nm (3.7 lbf ft) –

Screw, cooler retaining bracket M6 7 Nm (5.2 lbf ft) –

Screw, cover part M6 6 Nm (4.4 lbf ft) –

Screw, engine guard M6 10 Nm (7.4 lbf ft) –

Screw, exhaust clamp M6 8 Nm (5.9 lbf ft) –

Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, front brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, fuel pump M6 6 Nm (4.4 lbf ft) –

Screw, fuel tank M6 10 Nm (7.4 lbf ft) –

Screw, fuel tap M6 6 Nm (4.4 lbf ft) –

Screw, headlight M6 5 Nm (3.7 lbf ft) –

Screw, lower rear part M6 6 Nm (4.4 lbf ft) –

Screw, magnetic holder on side stand M6 6 Nm (4.4 lbf ft) Loctite

243™

Screw, rear brake disc M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, retaining bracket, angle sensor M6 10 Nm (7.4 lbf ft) –

Screw, voltage regulator M6 6 Nm (4.4 lbf ft) –

Screw, wheel speed sensor, front M6 10 Nm (7.4 lbf ft) –

Screw, wheel speed sensor, rear M6 10 Nm (7.4 lbf ft) –

Angle valve M8 4 Nm (3 lbf ft) –

Hand guard screw M8 15 Nm (11.1 lbf ft) –
