KTM LC4 ADVENTURE R 640 2000 User Manual

ENGLISH
38
TECHNICAL DATA - CHASSIS LC4 ADVENTURE R 640 2000
LC4 ADVENTURE R 640
Frame Central chrome-moly-steel frame
Fork WP-Extreme Ø 50 mm
Wheel travel front/rear 280 / 320 mm (11,0 / 12,6 in)
Rear suspension Central shock absorber WP IBS with PRO-LEVER linkage to rear- swing-arm with needle bearing
Front brake Disc brake with carbon-steel brake disc 300 mm (11,8 in), brake caliper floated
Rear brake Disc brake with carbon-steel brake disc 220 mm (8,7 in), brake caliper floated
Tyres front 90/90 - 21 54S Metzeler Enduro 3
Air press. road, driver only 1,5 bar (22 psi)
Air press. road with passenger 2,0 bar (29 psi)
Tyres rear 140/80 - 18 70R Metzeler Enduro 3
Air press. road, driver only 2,0 bar (29 psi)
Air press. road with passenger 2,2 bar (31 psi)
Fuel tank capacity 28 liter (7,4 US gallons), 3,5 liter (0,9 US gallons) reserve
Final drive ratio 16:42 t
Chain O – Ring
5
/8 x
1
/4"
Battery maintenance-free battery 12V 8Ah
Steering angle 62,5 °
Wheel base 1510 ± 10 mm (59,4 ± 0,4 in)
Seat high 955 mm (37,6 in)
Ground clearance 375 mm (14,8 in)
Dead weight without fuel 154kg (340 lbs)
Max. permissible front axle load 150 kg (331 lbs)
Max. permissible rear axle load
230 kg (507 lbs)
Max. permissible laden weight 380 kg (839 lbs)
01.18.R7.97
Compression adjuster 3
Rebound adjuster 5
Spring 70/260
Spring preload 23 mm (0,9 in)
STANDARD-ADJUSTMENT - SHOCK ABSORBER
09.18.S7.55
Compression adjuster 14
Rebound adjuster 12
Spring 4,4 N/mm
Spring preload 10 mm (0,4 in)
Air chamber length 155 mm (5,9 in)
Capacity per fork leg ca 800 ccm
Fork oil SAE5
STANDARD ADJUSTMENT - FORK
Collar screw front axle M 10 40 Nm (30 ft.lb)
Brake caliper front M8 Loctite 242 + 25 Nm (19 ft.lb)
Collar nut rear axle M 20x1,5 80 Nm (59 ft.lb)
Collar nut connecting rod pro lever system M12x1,75 60 Nm (44 ft.Ib)
Hex. nut swing arm bolt M 14x1,5 100 Nm (74 ft.lb)
Clamping screw upper fork bridge M 8 15 Nm (11 ft.lb)
Clamping screw lower fork bridge M 8 20 Nm (15 ft.lb)
Clamping screws fork stubs M 8 10 Nm (7 ft.lb)
Other screws chassis M6 10 Nm (7 ft.lb)
M8 25 Nm (19 ft.lb)
M10 45 Nm (33 ft.lb)
TORQUES
