12 SERVICE WORK ON THE CHASSIS 82
12.6 Mounting the front rider's seat
401921-10
–
Attach recesses
on the front rider's seat to the fuel tank, push the front rider's seat
forward, and lower at the rear.
Catch
engages in the recess.
– Check that the front rider's seat is correctly mounted.
12.7 Removing the passenger seat
Preparatory work
– Remove the front rider's seat. ( p. 81)
L02191-10
Main work
–
Remove screw
with the washer.
– Lift and take off the passenger seat.
