12 SERVICE WORK ON THE CHASSIS 93

12.15 Mounting the battery cover

M00451-10

Main work

–

Position battery cover



and pull toward the rear.

The battery cover engages with an audible click.

– Check the battery cover is seated correctly.

Finishing work

– Mount the front rider's seat. ( p. 82)

12.16 Removing the front spoiler

Preparatory work

– Remove the right side cover. ( p. 100)

– Remove the left side cover. ( p. 97)

L02258-10

Main work

–

Remove screws


