Kubota B2301 User Manual

3SPECIFICATIONS
NOTE: * SAE J1995 The company reserves the right to change the specifications without notice.
Hydraulic unit
Hydraulic control system Position control
Pump capacity
L / min
(gals / min)
31.4 (8.3)
3-point hitch SAE Category 1
Max. lift force
At lift points kg (lbs.) 820 (1808)
24 in.behind
lift point
kg (lbs.) 640 (1411)
PTO
Rear-PTO SAE 1-3/8, 6 splines
PTO / Engine speed rpm
1 speed
540 / 2768
Mid-PTO USA No. 5 (KUBOTA 10-tooth) involute spline
PTO / Engine speed rpm
1 speed
2500 / 2753
Model B2301HSD B2601HSD

Kubota B2301 Specifications

General

Engine Type	Diesel
Transmission Type	Hydrostatic
Type	Compact Utility Tractor
Drive	4WD
3-Point Hitch Category	Category I
Fuel Capacity	6.1 gallons
Hydraulic System Capacity	3.7 gallons
