22 PERIODIC SERVICE
ENGLISH
[D1503-M-E3, D1703-M-E3, D1803-M-E3, V2003-M-E3,
V2203-M-E3, V2403-M-E3, V2403-M-T-E3, D1803-M-DI-E3,
V2403-M-DI-E3]
[V3600-E3, V3600-T-E3, V3300-E3BG, V3600-T-E3BG]
BCleaning the fuel filter pot
Every 100 hours of operation, clean the fuel filter in a
clean place to prevent dust intrusion.
1. Close the fuel filter lever.
2. Remove the top cap, and rinse the inside with diesel
fuel.
3. Take out the element, and rinse it with diesel fuel.
4. After cleaning, reinstall the fuel filter, keeping out of
dust and dirt.
5. Air-bleed the injection pump.
A Entrance of dust and dirt can cause a malfunction of
the fuel injection pump and the injection nozzle.
Wash the fuel filter cup periodically.
(1) Clamp band
(2) Fuel pipe
(1) Clamp band
(2) Fuel pipe
(1) Fuel filter lever
(2) Fuel filter pot
(A) "OFF"
(B) "ON"
(1) O ring
(2) Filter element
(3) Spring
(4) Filter bowl
(5) Screw ring
To Next Page
