Model
RTV520
General purpose Deluxe
Cargo bed
Volume m
3
(cu.ft.) 0.25 (8.9)
Bed height (unloaded) mm (in.) 874 (34.4)
Max. cargo bed capacity kg (lbs.) 200 (440)
Tires
Front
24 × 9-12 ATV, 6PLY: Steel
24 × 9-12 HDWS, 6PLY: Steel
24 × 9-12 ATV, 6PLY: Aluminum
24 × 9-12 HDWS, 6PLY: Aluminum
Rear
24 × 11-12 ATV, 6PLY: Steel
24 × 11-12 HDWS, 6PLY: Steel
24 × 11-12 ATV, 6PLY: Aluminum
24 × 11-12 HDWS, 6PLY: Aluminum
Front guard Opt. Standard
Body color Orange / Camo
Speedometer Opt.
Rear net Opt.
*1 SAE J1349 Net
NOTE :
• The company reserves the right to change the specifications without notice.
• The values in “Ground clearance” and “Weight” are those of the machine equipped with the tires in the
table above.
TRAVELING SPEEDS
Model RTV520
Range gear shift lever km/h (mph)
Low 16 (10)
High 40 (24.9)
Reverse 23 (14.3)
TRAVELING SPEEDS SPECIFICATIONS
