OPERATING THE GENERATOR16
A For the AUS specified models, turn ON the load center
circuit breaker that corresponds to the receptacle
being used.
COLD WEATHER STARTING
If the ambient temperature is below * -5 C (23 F) and the
engine is very cold, start it in the following manner:
Take steps (1) through (5) in "STARTING THE ENGINE"
section.
A If the ambient temperature is low, the preheating time
will take longer.
A Shown below are the standard preheating times for
various temperatures. This operation, however, is not
required, when the engine is warmed up.
(If the engine fails to start after 10 seconds, turn off the
key for 30 seconds. Then repeat steps (6) and (7) above.)
A Do not allow the starter motor to run continuously for
more than 10 seconds.
A Be sure to warm up the engine, not only in winter, but
also in warmer seasons. An insufficiently warmed-up
engine can shorten its service life.
A When there is possibility of temperature drops below
-15 C (5 F) detach the battery from the machine, and
keep it indoor in a safe area. Reinstalled the battery
before the next operation.
11. Turn ON the circuit breaker on the
control panel.
(1) Circuit breaker (A) "ON"
12. Turn ON the electrical device switches
for the connections.
6. Turn the main switch (key) to the
"GLOW" position until the glow plug
indicator goes off.
7. Turn the key to "ST" ("START") position
and the engine should start.
Ambient temperature Preheating time
Above 10 C (50 F) NO NEED
10 C (50 F) to
-5 C (23 F)
Approx. 5 seconds
*Below -5 C (23 F)
Approx. 10 seconds
Limit of continuous use 20 seconds
1G296-8914.book 16 ページ ２０１２年３月１９日 月曜日 午前１０時４０分
To Next Page
