4 INSTRUMENT PANEL AND PART NAMES
INSTRUMENT PANEL AND PART NAMES
MOKUJIYOU
BControl Panel
C 1 Phase Type
[SQ-1120, SQ-1150]
C 3 Phase Type
[SQ-3140, SQ-3200, SQ-3300]
(1) A.C. Voltmeter
(2) Frequency meter
(3) A.C. Ammeter
(4) Pilot lamp (Green lamp)
(5) Glow plug lamp
(6) Water temperature lamp
(7) Oil pressure lamp
(8) Battery charge lamp
(9) Main switch (key)
(10) Circuit breaker
(11) Voltage adjuster
(12) Terminals (output)
(13) Hour meter
(14) Ground terminal
(15) Door open lamp
(16) Fuel gauge
(1) A.C. Voltmeter
(2) Frequency meter
(3) A.C. Ammeter
(4) Pilot lamp (Green lamp)
(5) Glow plug lamp
(6) Water temperature lamp
(7) Oil pressure lamp
(8) Battery charge lamp
(9) Main switch (key)
(10) Circuit breaker
(11) Voltage adjuster
(12) Terminals (output)
(13) Hour meter
(14) Ground terminal
(15) Voltmeter change-over switch
(16) Ammeter change-over switch
(17) Door open lamp
(18) Fuel gauge
