Kubota V3300-E User Manual

30 SPECIFICATIONS
ENGLISH
SPECIFICATIONS
A Specifications are subject to change without notice.
Model V3300-E V3300-TE
Type Vertical, water-cooled, 4-cycle diesel
Number of cylinders 4
Bore and stroke mm (in.) 98 × 110 (3.86 × 4.33)
Total displacement L (cu.in.) 3.318 (202.49)
Combustion type Spherical type (E-TVCS)
SAE NET Intermittent
kW / rpm
H.P. (SAE J1349)
(HP / rpm)
50.5/2600
(67.7/2600)
61.5/2600
(82.4/2600)
SAE NET Continuous
kW / rpm
H.P. (SAE J1349)
(HP / rpm)
43.9/2600
(58.8/2600)
53.4/2600
(71.6/2600)
SAE Standby
kW / rpm
H.P. (SAE J1349)
(HP / rpm)
--- ---
Maximum bare speed rpm 2800
Minimum bare idling speed rpm 700 to 750
Order of firing 1-3-4-2
Direction of rotation Counter-clockwise (viewed from flywheel side)
Injection pump Bosch type mini pump
Injection pressure
Mpa (kgf/cm
2
, psi)
13.73 (140, 1991)
Injection timing (Before T.D.C.) 0.28 rad (16°)
Compression ratio 22.6 21.8
Fuel Diesel fuel oil No.2-D
Lubricant
(API classification)
above CF grade
Dimensions mm (in.)
(length × width × height)
743 × 536 × 759
(29.25 × 21.10 × 29.88)
743 × 538 × 793
(29.25 × 21.18 × 31.22)
Dry weight kg (lbs.) 241 (531) 250 (551)
Starting system Cell starter (with glow plug)
Starting motor 12V 2.5kW
Charging generator 12V 540W
Recommended battery capacity
12V, 112AH (400 CCA or higher) 0°F
(-17.8°C) SAE rating

Kubota V3300-E Specifications

General

Brand	Kubota
Model	V3300-E
Category	Engine
Language	English
