TIRES AND WHEELS32
ENGLISH
BRemove and Install Front Caster Wheels
C Removing
1. Park the machine on a firm and level surface.
2. Stop the engine and apply parking brake.
3. Lift the front of machine with a safe lifting device.
4. Remove the lock nut with nylon sleeve and wheel bolt.
5. Remove the wheel from assembly yoke.
C Installing
1. Install the replacement wheel.
2. Install the wheel bolt and lock nut with nylon sleeve.
3. Install the nut.
A Insert the wheel bolt from the outside of the yoke.
A Tighten the nut gradually until wheel bearing play is
eliminated and wheel turns freely by hand.
Reference
4. Lower machine.
Tightening torque
20 to 25 N-m
(14.8 to 18.4 ft-lbs)
(2 to 2.5 kgf-m)
(1) Lock nut
(2) Wheel bolt
(3) Yoke

Kubota ZD221 Specifications

General

Style	Zero Turn
Color	Red
Cutting Width	48/54 in
Cutting Height	1-5 in
Cutting Method	-
Number of Blades	3
Drive System	Cruise Control (Hydrostatic)
Case Size: U1R	CCA: 450A
Noise Level	-
Features	Superior Quality Cut
Accessories	-
Motor / Engine Model	Kubota D782
Power Output	-
Cylinders	3
Generator	-
Power / Fuel Type	Diesel
Fuel Tank Volume	23.0 liters (6.1 US gal.; 5.1 Imp. gal)
SAE 5W30 (below 32°F/0°C)	SAE 5W30
w/o Filter: 44 oz. (1	1.32 Imp. qt.)

Weight and Dimensions

Depth	2130 mm (83.9 in)
Height	1770 mm (69.7 in)
Width	1210 mm (47.6 in)
Net Weight	550 kg (1213 lbs)
