KPM8420T
Specifications
12
Model KPM8420T 8 Channel Dual Powered Mixer
200W per channel 4 Ohms @ 5% THD
180W per channel 4 Ohms @ 0.4% THD
-115dB Mic Input, Rs=150 ohm, 20-20kHz
-55dB Residual Noise, all level controls 0% (minimum)
-45dB Nominal System Noise, all level controls at 50%
90 dB Mic to Power Amp (Ch 1 - Ch8) Pad Off
77dB Mic to Power Amp (Ch 1 - Ch8) Pad On
72dB Line to Power Amp (Ch 1 - Ch8) Pad Off
60dB Line to Power Amp (Ch 1 - Ch8) Pad On
36dB Playback to Power Amp
50dB Mic to Main out, Pad On
50dB Mic to Monitor out, Pad On
50dB Mic to Record out, Pad On
Crosstalk 70dB Channel to Channel, 1kHz
Input Channel Equalization
Master Equalization
Phantom Power +40V Applied to all Mic inputs when active
USA/Canada 120VAC/60Hz, 300W nominal
Europe 230VAC/50Hz, 300W nominal
UK 230VAC/50Hz, 300W nominal
Australia 240VAC/50Hz, 300W nominal
Japan 100VAC/50-60Hz, 300W nominal
mm/kg 292 (Height) x 495 (W idth) x 305 (Depth), 15.6kg
Inches/Pounds 11.5 (Height) x 19 (W idth) x 12.1 (Depth), 34.4 lbs
Recommended: KUSTOM model KAC-FS-202 (dual switch with LEDs)
Small Room, Large Room, Small Hall, Double Take , Chorus, Chorus Reverb, Slapback, Delay
Module 2:
Short Room, Med Room, Small Hall, Med Hall, Chorus, Chorus Reverb, Chorus Hall, Short Delay
Digital effects On/Off and Channel ON/OFF (playback remains active)
Special curve that adjusts Bass, Mid, and Treble frequencies
100 to 10kHz, 7 Band, 1 Octave Graphic, all ±12dB
Module 1:
Two 24 bit DSP modules, 8 effects per module.
Total Harmonic Distortion
Frequency Response 20HZ-20kHz
Actual response is tailored to speaker cabinet for
accurate acoustical response.
Less than 0.4%
Measured at 1VRMS (0dBv) at record output, effects
send, preamp output, or Main output.
System Gain
Dimensions
Power Requirements
All Measurements made at 1kHz
Digital Effects
Output Power
Hum & Noise
Footswitch
