Kustom KPM 8420T User Manual

Left
Right
Record Output Light Control Output
Left Right
Playback Subwoofer Output
On
Main
Main
Phantom
Power
Power Amp
Assignment
Off
Monitor
Monitor
Preamp
Output
Power Amp
Input
Main A
Monitor B
CD/Tape
46
44
45
40
38
39
47
48
43
42
41
PATCH BAY
CD / TAPE PLAYBACK
CD / TAPE RECORD OUTPUT
PHANTOM ON/OFF
SUB WOOFER OUTPUT
LIGHT CONTROLLER OUTPUT
PREAMP OUTPUT MAIN
PREAMP OUTPUT MONITOR
POWER AMP ASSIGN A
POWER AMP ASSIGN B
POWER AMP INPUT A
POWER AMP INPUT B
Jacks:
Jacks:
Switch:
Jack:
Jack:
:
:
Switch:
Switch:
:
:
These RCA jacks are used to play audio from CD,
Tape, Computer, DVD, Hard Disc, MP-3 or other
line level audio source. NOTE: Use the
PLAYBACK controls (#21 & #27) to adjust the
volume of the playback to the Main and Monitor
sections.
These RCA jacks deliver a MONO Line level
output to a recording device such as Tape
Recorder, Computer, Recordable DVD, Hard Disc,
MP-3 and more.
This switch turns on the phantom power to the
XLR input Jacks. This power supply is designed
to provide power for condenser microphones and
other devices.
This is a low pass sub woofer output. Crossover
point = 150 hz @ 12db/oct.
This is selective band-pass output designed to
deliver a Line level audio trigger signal to Lighting
Controller devices.
This ¼” Mono jack delivers a Line level output
from the MAIN Master section.
This ¼” Mono jack delivers a line level output
from the MONITOR Master section.
This switch determines which master section will
drive the A power-amp. Place the switch in the UP
position to have the MAIN mix signal to the A
power-amplifier. Place the switch in the down
position to have the MONITOR mix signal to the A
power-amplifier.
This switch determines which master section will
drive the B power-amp. Place the switch in the UP
position to have the MAIN mix signal to the B
power-amplifier. Place the switch in the down
position to have the MONITOR mix signal to the
B power-amplifier.
This ¼” Mono jack allows the A power-amplifiers
to be used with an external Line level input.
NOTE: When used, this jack will interrupt the
signal flow from the mixer section of the
KPM8420T.
This ¼” Mono jack allows the B power-amplifiers
to be used with an external Line level input.
NOTE: When used, this jack will interrupt the
signal flow from the mixer section of the
KPM8420T.
40V
9
