2. FRAME COVERS/EXHAUST MUFFLER
2-3
FRAME COVERS
HANDLEBAR COVER REMOVAL
Remove the two screws attaching the
handlebar cover.
Disconnect the oil level indicator leads.
Remove the handlebar cover.
INSTALLATION
Reverse the “HANDLEBAR COVER
REMOVAL” procedures.
SEAT REMOVAL
To remove the seat, pull upward the seat
lock lever and pull up the seat at the rear.
To install the seat, align the tabs on the seat
with the grommets on the frame and press
the seat down until it locks.
HANDLEBAR REMOVAL
Remove handlebar cover. (See page 2-3)
Remove the rear brake master cylinder
attaching bolts (disk brake).
Disconnect the rear brake cable (drum
brake).
Disconnect the handlebar switch coupler
and lead (under front fender).
Bolts
Handlebar Cove
r
Seat Lock Leve
r
Sea
t
Make sure that the seat is securely fitted.
＊
Bolts
Handlebar Switch Coupler and Lead
