KYMCO MXU550i T3B ABS User Manual

8-14
8.4. REAR GEAR BOX OIL
Change the oil in the rear gear box case when specified by the
Maintenance Schedule. Change the oil with the rear gear box
warm, and the ATV on level ground to assure complete and
rapid draining. Rear gear box oil replacement
To drain the oil, first place an oil drain pan under the oil drain
plug (1).
(1) Oil drain plug
(2) Oil filler cap
(3) Oil level check bolt/ washer
1. Remove the oil filler cap (2), and then remove the drain
plug/washer.
2. After the oil has completely drained, reinstall the drain
plug/washer.
Tightening Torque
Drain plug 20 N-m (2 kgf-m, 15 lbf-ft)
