4-2
4.2. INSTRUMENTS AND INDICATOR
(1) MODE Button
(2) Engine Tachometer
(3) ADJ Button
(4) High Beam Indicator
(5) EFI System Indicator
(6) Neutral Gear Position Indicator
(7) Multifunction Display
(8) Turn Signal Indicator
(9) Park Indicator Light
(10) EPS Warning Light(EPS MODEL ONLY)
(11) Coolant Temperature Warning Indicator
(12) Brake Level Warning Indicator
(1) Mode Button
This button is used to switch km/h, mph, km and mile.
This button is also used to adjust the time and reset the trip of
meter.
(2) Engine Tachometer
The electronic tachometer allows the rider to monitor the
engine speed and keep it within the power range. When the key
is turned to “ON”, the tachometer will lights on once all range
and then goes off in order to test the electrical circuit.
NOTE
Do not operate the engine in the tachometer high-rpm zone.
High zone: 8000 r/min and above
