4-23
4.8. SPEED LIMITER
The speed limiter keeps the throttle from fully opening, even
when the throttle lever is pushed to the maximum. Screwing in
the adjuster limits the maximum engine power available and
decreases the maximum speed of the ATV.
(1) Adjuster
(2) Locknut
(3) 13mm (0.52in)
POTENTIAL HAZARD
Improper adjustment of the speed limiter and throttle.
WHAT CAN HAPPEN
The throttle cable could be damaged.
Improper throttle operation could result. You could lose control,
have an accident or be injured.
HOW TO AVOID THE HAZARD
Do not turn the speed adjuster out more than 13 mm (0.52 in).
Always make sure the throttle lever free play is adjusted to
3~5mm (0.12~0.2 in).
