n Route harnesses so they are neither
pulled tight nor have excessive slack.
n Protect wires and harnesses with electrical
tape or tube if they contact a sharp edge or
corner.
n When rubber protecting cover is used to
protect the wire harnesses, it shall be
installed securely.
n Do not break the sheath of wire.
n If a wire or harness is with a broken sheath,
repair by wrapping it with protective tape
or replace it.
n When installing other parts, do not press or
squeeze the wires.
n After routing, check that the wire harnesses
are not twisted or kinked.
n Wire harnesses routed along with handlebar
should not be pulled tight, have excessive
slack or interfere with adjacent or
surrounding parts in all steering positions.
n When a testing device is used, make sure to
understand the operating methods
thoroughly and operate according to the
operating instructions.
n Be careful not to drop any parts.
n When rust is found on a terminal, remove
the rust with sand paper or equivalent
before connecting.
n Do not bend or twist control cables.
Damaged control cables will not operate
smoothly and may stick or bind.
n Symbols:
The following symbols represent the
servicing methods and cautions included in
this service manual.
: Apply engine oil to the
specified points. (Use
designated engine oil for
lubrication.)
: Apply grease for lubrication.
: Transmission Gear Oil (90#)
: Use special tool.
: Caution
: Warning
