8. CYLINDER/PISTON
8-5
PEOPL E 12 5/150
Inspect the piston, piston pin and piston
rings.
Remove the piston rings.
Clean carbon deposits from the piston ring
grooves.
Install the piston rings onto the piston and
measure the piston ring-to-groove clearance.
Service Limits: Top: 0.09mm replace if over
2nd: 0.09mm replace if over
Remove the piston rings and insert each
piston ring into the cylinder bottom.
Measure the piston ring end gap.
Service Limit: 0.5mm replace if over
Measure the piston pin hole I.D.
Service Limit: 15.04mm replace if over
Take care not to damage or break the
piston rings during removal.
＊
Use the piston head to push each piston
ring into the cylinder.
＊
Piston Rings
www.PlanDeGraissage.org

KYMCO PEOPLE 125 Specifications

General

Displacement	124.6 cc
Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Starter	Electric & Kick
Cooling System	Air Cooled
Transmission	Automatic CVT
