20
CONTROLS & FEATURES
Seat
To unlock the seat
With the ignition key in the " " position (the
engine is running), push the key in and turn it
counterclockwise from " " to the " "
position.
With the ignition key in the " " position
(the engine is not running), turn the
counterclockwise from the " " to the
" " position.
With the ignition key in the " "position,
turn the key counterclockwise from " "
to " "position. Pull up on the back
portion of the seat to lift it up.
Open the seat by pulling up the rear end of
seat. You can separate the under-seat
luggage box into two parts with the plastic
panel .
Maximum cargo weight:
LUGGAGE BOX.........................10KG
REAR CARRIER ..........................5KG
3
4
5
6
1
2
1
2
3
