22
CONTROLS & FEATURES
Suspension
Each shock absorber assembly is equipped
with a spring preload adjusting ring.
Adjust the spring preload as follows.
To increase the spring preload and thereby
harden the suspension, turn the adjusting
ring on each shock absorber assembly in
direction (a). To decrease the spring preload
and thereby soften the suspension, turn the
adjusting ring on each shock absorber
assembly in direction (b).
Align the appropriate notch in the adjusting
ring with the position indicator on the shock
absorber.
3
4
5
6
WARNING
Be certain to adjust both shock absorber
to the same spring preload position.
Improper setting of shock absorber will
cause unstable handling and might lead
to an accident.
1. Spring preload adjusting ring
2. Position indicator
3. Spring preload adjusting too
