20
Correcting a Paper Jam
If a paper jam occurs while you are printing, remove the jammed paper as
described below. After you have removed the jammed paper, open and close the
top cover or the paper transfer unit.
When pulling the paper, pull it gently so as not to tear it. Torn pieces of
paper are difficult to remove and may be easily overlooked, deterring the
jam recovery.
Jam at the Rear Cover
1 While pulling the paper transfer unit release lever (green colored), pull out the
paper transfer unit.
2 Open the rear cover and remove the jammed paper as shown in the figure.
Paper Transfer Unit
Paper Transfer Unit Release
Lever (green colored)
Rear Cover
FS3830NIG.book 20 ページ ２００３年１２月１２日 金曜日 午前１０時０分
To Next Page
