Kyocera ECOSYS P2135d Service Manual

2PG/2PH
1-4-10
(1) Completely blank printout.
(2) All-black printout.
Print example Causes Check procedures/corrective measures
Defective drum unit or developing
unit.
Open the top cover and check that the drum unit and develop-
ing unit are correctly seated. Investigate that the terminals
between the main charger unit and the drum unit are not in
loose contact (See page 1-5-12 and 1-5-12).
Defective transfer bias output or
developing bias output.
Replace the high voltage PWB (See page 1-5-25).
Poor contact of developing bias termi-
nal (spring) and high voltage output
terminal B (J401, J402, J403) on the
high voltage PWB.
Poor contact of transfer bias terminal
(spring) and transfer bias terminal T
(J201, J202, J203) on the high volt-
age PWB.
Check the high voltage PWB visually and correct or replace if
necessary (See page 1-5-25).
Defective laser scanner unit. Replace the laser scanner unit (See page 1-5-30).
Defective control PWB. Replace the control PWB (See page 1-5-19).
Print example Causes Check procedures/corrective measures
Defective main charger unit. Open the top cover and check that the drum unit and develop-
ing unit are correctly seated (See page 1-5-11).
Investigate that the terminals between the main charger unit
and the drum unit are not in loose contact.
Poor contact of main charger terminal
(spring) and main charger output ter-
minal M on the high voltage PWB.
Check the high voltage PWB visually and correct or replace if
necessary (See page 1-5-25).
Defective main charging output. Replace the high voltage PWB (See page 1-5-25).
Broken main charger wire. Replace the main charger unit (See page 1-5-13).
Defective control PWB. Replace the control PWB (See page 1-5-19).

Kyocera ECOSYS P2135d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Maximum number of input trays	4
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.4 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	50 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
