Kyocera TASKalfa 6500i User Manual

Management
10-15
10
Obtain NW User Property
Set the required information to obtain the network user property from the LDAP server.The user name and
e-mail address obtained with this setting is shown in the user information, the status confirmation screen, and
the header of e-mail.
NOTE: To obtain the network user property from the LDAP server, [Network Authentication] must be selected
for the authentication method in User Login on page 10-2. Select [On] for LDAP in Protocol Detail on page 9-
94.
The table below explains the required information to be registered.
*1 If using Active Directory of Windows, the server name may be the same as the server name entered in the
network authentication.
*2 If using Active Directory of Windows, displayName of Attribute may be used as Name 1.
*3 Name 2 can be left out. When you assign displayName in Name 1 and department in Name 2, and if the
value of displayName is "Mike Smith" and the value of department is "Sales" in Active Directory of Windows,
the user name appears as Mike Smith Sales.
*4 If using Active Directory of Windows, mail of Attribute may be used as E-mail Address.
*5 Appears when the server type is set to "Kerberos" in "Network Authentication".
Use the procedure below.
1 Press the System Menu key.
2 Press [User Login/Job Accounting].
3 If the user authentication screen appears, enter
your login user name and password and then press
[Login]. For this, you need to login with
administrator privileges. Refer to Adding a User
(Local User List) on page 10-5 for the default login
user name and password.
Item Description
Server Name*
1
Enter the LDAP server name or the IP address (up to 64 characters). If a server
name is not entered, user information will be acquired from the server set for
Network Authentication.
Port Set the LDAP port number or use the default port 389.
Name 1*
2
Enter the LDAP Attribute to obtain the user name to be displayed from the
LDAP server (up to 32 characters).
Name 2*
3
Enter the LDAP Attribute to obtain the user name to be displayed from the
LDAP server (up to 32 characters).
E-mail Address*
4
Enter the LDAP Attribute to obtain the e-mail address from the LDAP server (up
to 32 characters).
Authenticat Type*
5
Set the authentication method. Select [Simple] or [SASL]. After changing the
setting, restart the system or turn the power off and then on.
Search Timeout Set the amount of time to wait before time-out in seconds (from 5 to 255
seconds).
LDAP Security Select the type of encryption according to the type of security employed by the
LDAP server. The default setting is OFF.

Kyocera TASKalfa 6500i Specifications

General

Network ready	Yes
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	1039 x 723 x 1347 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	Scan
DVD/CD printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.2 s
Print speed (black, normal quality, A3)	32 ppm
Print speed (black, normal quality, A4/US Letter)	65 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Copier resize	25 - 400 %
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, OCR, USB
Grayscale levels	256
Maximum scan area	A3 (297 x 420) mm
Scan speed (black)	160 ppm
Scan speed (color)	100 ppm
Image formats supported	JPG, TIF
Faxing	Mono faxing
Fax memory	120 MB
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Paper input type	Paper tray
Total input capacity	4150 sheets
Total output capacity	420 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Maximum print size	297 x 420 mm
Duplex media weight	60 - 256 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 300 g/m²
Display	LCD
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Processor model	750CL
Processor family	PowerPC
Compatible memory cards	CF
Internal storage capacity	320 GB
Sound power level (standby)	58 dB
Sound pressure level (printing)	75 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	300 W
Power consumption (PowerSave)	20 W
Power consumption (average operating)	1210 W
Sustainability certificates	ENERGY STAR
Certification	TÜV/GS, CE, RoHS
