Operator's Manual – Mega Stacker
© LAI GAMES
Page 48
LAMPS
COIN DOOR LAMPS
The coin door lamps all are 12V/DC LED or equivalent and can be accessed through
the coin door.
BUTTON LAMPS
The button lamps all are 12V/DC LED or equivalent and can be accessed inside the
control panel
PLATFORM LAMPS
There are, 3 x 18 Watt (24”) and 6 x 15 Watt (18”) fluorescent tubes in base platform.
Access is from the top and side of the platform.
HEADER LAMPS
These are 2 x 36 Watt (48”) fluorescent tubes in the Header of the cabinet. Access is
from the back of the header.
* WARNING! *
Always turn OFF Mains power and unplugged the game, before replacing any
lamps.
Always allow time for cooling as Lamps that have been active for a time may still
be too hot to touch.
* CAUTION! *
Always replace the lamps with the same or equivalent size, wattage and voltage.
