Operator's Manual – Mega Stacker
© LAI GAMES
Page 59
CONNECTION INFORMATION
BAFB66 EDGE CONNECTOR
Components Side
Solder side
GND 1
A GND
GND 2
B GND
+12VDC 3
C +12V
+12VDC 4
D +12V
Continue Button Input P1A7 5
E P1B7 Test button Input
Unlock Switch 5 P1A6 6
F P1B6 Service button Input
Lock Switch 5 P1A5 7
H P1B5 Start Button Input
Door Sensor 5 Input P1A4 8
J P1B4 FB 151 WDD Input
Door Sensor 4 Input P1A3 9
K P1B3 Ticket Notch Input
Door Sensor 3 Input P1A2 10
L P1B2 Coin 1 Mech. Input
Door Sensor 2 Input P1A1 11
M P1B1 Coin 2 Mech. Input
Door Sensor 1 Input P1A0 12
N P1B0 Step Button Input
P1C7 13
P P2C7 (watchdog), Seven Segment Data
Door 2 Open Indicator P1C6 14
R P2C6 Reset FB151
Door 1 Open Indicator P1C5 15
S P2C5 Door 2 Close Indicator
Prize 5 Select Indicator P1C4 16
T P2C4 Door 1 Close Indicator
Prize 1 Select Indicator P1C0 17
U P2C0 RSL Board 1 Data
Prize 2 Select Indicator P1C1 18
V P2C1 RSL Board 2 Data
Prize 3 Select Indicator P1C2 19
W P2C2 RSL Board 3 Data
Prize 4 Select Indicator P1C3 20
X P2C3 7Seg,RSL Board Clock
GND 21
Y GND
GND 22
Z GND
JST 7
JST 5
Door 3 Close Indicator P2A0 1
1 P2B0 Capsule/Ticket Dispenser Drive
Door 4 Close Indicator P2A1 2
2 P2B1 Capsule/Ticket Counter
Door 5 Close Indicator P2A2 3
3 P2B2 Coin1 Counter
Win Lamp 2 P2A3 4
4 P2B3 Coin2 Counter
Win Lamp 1 P2A4 5
5 P2B4 Prize Counter
Door 3 Open Indicator P2A5 6
6 P2B5 Start Button Light
Door 4 Open Indicator P2A6 7
7 P2B6 Step Button Light
Door 5 Open Indicator P2A7 8
8 P2B7 Continue Button Light
