Using the Lantronix SGX 5150 Serial Device Server

Appendix F – Switched Power Control for Campbell Dataloggers

Campbell Scientific dataloggers include programmable power outputs, such as Switch 12 (SW12), which can

be used to control power to connected devices, such as the Lantronix SGX 5150.

(Figure 28)

SW12 provides a programmable output of 12 volts to the connected device and by doing so, the following can

be achieved:

• Power cycle the connected device, allowing a reconnection to the local Wi-Fi network.

• Reducing the power consumption of an entire unit by turning power on at specified times rather than

being continuously powered.

To use switch power control, the datalogger program must be updated and the device’s power inputs must be

rewired to connect to SW12 instead of the charge regulator.

Note

−

Devices that requires more than 1 amp of power cannot be powered through SW12. If a device

requires more than 1 amp of power, contact Canary Systems.

Other manuals for Lantronix SGX 5150

Questions and Answers:

Need help?

Do you have a question about the Lantronix SGX 5150 and is the answer not in the manual?

General

Certification	FCC ICES-003:2012 RED 2014/53/EU, EMCD 2014/30/EU, EN 300 328 V1.9.1, EN 301 489-1 V1.9.2, EN301 489-17 V2.2.1, EN 301 893 V1.8.1, EN 62311: 2008 AS/NZS CISPR 22, AS/NZS 4268: A1: 2013, AS/NZS 2772.2VCCI EN 55022:2010, EN 55024:2010, EN 61000-3-2:A2 2009, EN 61000-3-3: 2008 UL 60950/CSA 22.2 No. 60950, IEC 60950 CE LVD 2014/35/EU
LED indicators	Yes
Power requirements	9 - 30 VDC
Power over Ethernet (PoE)	No
Power consumption (typical)	1.9 W
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Security algorithms	802.1x RADIUS, AES, EAP-FAST, EAP-PEAP, EAP-TLS, EAP-TTLS, FIPS 140-2, MSCHAPv2, TKIP, WPA, WPA2, WPA2-PSK, WPS
Authentication method	RADIUS
Ethernet LAN (RJ-45) ports	1
Supported protocols	IPv4/IPv6, TCP, UDP, ICMP, ARP, Auto-IP, DNS, (S)FTP
Frequency band	2.4 / 5 GHz
Cabling technology	10/100BASE-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s

Weight and Dimensions

Weight	350 g
Dimensions (WxDxH)	110 x 89 x 26 mm
