18 / 34 Puridest Glass Distillation Apparatus 09/2020
Puridest Glass Bi Distillation Apparatus models PD 2 DG and PD 4 DG
PD 2 DG
PD 4 DG
Exterior dimensions (W x D x H)
685 mm x 360 mm x 410 mm
685 mm x 360 mm x 410 mm
Distillation capacity
2 l / h bi distillate
4 l / h bi distillate
Distillate quality
Bi distillate
approx. 1.6 µS / cm at 25 °C
in conformity with DAB, bacteria and pyrogen free, low
gas content.
Bi distillate
approx. 1.6 µS / cm at 25 °C
in conformity with DAB, bacteria and pyrogen free, low
gas content.
The conductivity of the distilled water is directly related to the chemical composition of the raw water. Components of the raw water having the same or
a lower evaporation point than water may deteriorate the conductivity.
Cooling water required
72 l / h
144 l / h
Low water cut-off
Electromechanical temperature limiter, with capillary
tube sensor.
Switch-off temperature 135 °C / -15 K
Electromechanical temperature limiter, with capillary
tube sensor.
Switch-off temperature 135 °C / -15 K
Water pressure min. / max.
> 3 bar / 7 bar
> 43.5 psi / 101.5 psi
> 3 bar / 7 bar
> 43.5 psi / 101.5 psi
Electrical connection
Mains supply /
On-site fuse
230 V +/-10 %, 50 / 60 Hz, 2.9 kW
Mains connection cable with Schuko plug,
internal 2 x 15 A inert, on-site 16 A inert
220 V / 3 ~ / PE, +/-10 %, 50 / 60 Hz, 5.8 kW
Mains connection cable for permanent connection to
the mains, on-site 3 x 25 A inert
or
400 V / 3 ~ / N / PE, +/-10 %, 50 / 60 Hz, 5.8 kW
Mains connection cable for permanent connection to
the mains, on-site 3 x 16 A inert
Caution! Mains voltage deviations, even with the mentioned limits, influence the quantity of distillate produced.
Protection class / - type
I / IP20
I / IP20
Surrounding conditions
Use only inside buildings (not in potentially explosive ar-
eas).
Use only inside buildings (not in potentially explosive ar-
eas).
Height above MSL
up to 2000 m MSL
up to 2000 m MSL
Ambient temperature
+10 °C to +40 °C
+10 °C to +40 °C
Humidity
max. 80 % rel. humidity to 31 °C, decreasing to 40 %
rel. humidity at 40 °C
max. 80 % rel. humidity to 31 °C, decreasing to 40 %
rel. humidity at 40 °C
Net Weight
43.0 kg
43.0 kg
Weight with water filling
68.4 kg
68.4 kg
