Lauda PD 2 G - Connection to the Mains Supply (Examples); PD 2 G, PD 4 G and PD 2 DG for 230 V at Mains Supply 220 V; 3 ~; PE 50; 60 Hz

09/2020 Puridest Glass Distillation Apparatus 25 / 34
Connection to the mains supply (examples)
Components
B1 Shock-proof socket, on-site
B2 Shock-proof plug, assembled
B3 CEE plug, not assembled, according to IEC standard 60309-2
F6 Mains fuse (on-site)
F7 Mains fuse (on-site)
F8 Mains fuse (on-site)
S4 Main switch (on-site)
13.1.1 PD 2 G, PD 4 G and PD 2 DG for 230 V at Mains supply 220 V / 3 ~ / PE 50 / 60 Hz
(see nameplate)
PD 2 G, PD 4 G and PD 2 DG for 230 V
Mains connection through CEE plug 7/7 (pre-assembled), all-pole
separation from the mains possible.
13.1.2 PD 2 G, PD 4 G and PD 2 DG for 230 V at Mains supply 220 V / 3 ~ / PE 50 / 60 Hz
(see nameplate)
PD 2 G, PD 4 G and PD 2 DG for 230 V
Mains connection through CEE plug 7/7 (pre-assembled), all-pole
separation from the mains possible.
