36
intermediate position between the closed and fully
opened position, according to the kind of cleaning
to be performed.
Solution water valve closed
Solution water valve partially opened
Solution water valve fully opened
6.12. DRIVING THE MACHINE
Model AC 230V
- Connect the power cable of the machine (Pho-
toB-16) to the power mains using a patch cord.
- Switch ON the main ON-OFF switch (PhotoE-32) .
Activate the “smart run” brush activation switch
(Photo E-33), both brush motor and suction motor
will turn on and the two corresponding warning
lights will turn on.
To activate the “Eco” energy saving mode of the brush
press and hold for 2 seconds the button (Photo E-33),
the corresponding warning light will start flashing. To
go back to standard mode press and hold the button
until the corresponding warning light remains on.
To activate the “Eco” energy saving mode of the suc-
tion press and hold for 2 seconds the button (Photo
E-34), the corresponding warning light will start flash-
ing. To go back to standard mode press and hold the
button until the corresponding warning light remains
on.
The brush will start rotating only after acti-
vating the drive lever (Photo A-2) and the corre-
sponding warning light will turn on (Photo E-32A).
Open the detergent tap by rotating the detergent
dosing lever (Photo C-22).
If you do not wish to use the detergent press the but-
ton (Photo E-35) and the corresponding warning light
will turn off.
Lower the suction unit through the squeegee lifting
lever (Photo B-19).
Wash the floor by slowly moving forward and pulling
the drive lever (Photo A-2) to activate the brush; upon
drive lever release brush rotation will stop after a few
seconds.
Remember to lift the squeegee before moving
backward to avoid damaging it.
If you do not wish to use the brush press the button
(Photo E-33) and the corresponding warning light will
turn off.
If you do not wish to use the suction press the button
(Photo E-34) and the corresponding warning light will
turn off.
Model DC 2 x 12V
- Verify that the battery connector placed under the
recovery tank (PhotoB-17) is connected.
Activate main switch (PhotoE-32).
Activate the “smart run” brush activation switch
(Photo E-33), both brush motor and suction motor
will turn on and the two corresponding warning
lights will turn on.
To activate the “Eco” energy saving mode of the brush
press and hold for 2 seconds the button (Photo E-33),
the corresponding warning light will start flashing. To
go back to standard mode press and hold the button
until the corresponding warning light remains on.
To activate the “Eco” energy saving mode of the suction
press and hold for 2 seconds the button (Photo E-34),
the corresponding warning light will start flashing. To
go back to standard mode press and hold the button
until the corresponding warning light remains on.
The brush will start rotating only after acti-
vating the drive lever (Photo A-2) and the corre-
sponding warning light will turn on (Photo E-32A).
Open the detergent tap by rotating the detergent
dosing lever (Photo C-22).
If you do not wish to use the detergent press the but-
ton (Photo E-35) and the corresponding warning light
will turn off.
Lower the suction unit through the squeegee lifting
lever (Photo B-19).
Wash the floor by slowly moving forward and pulling
the drive lever (Photo A-2) to activate the brush; upon
drive lever release brush rotation will stop after a few
seconds.
Remember to lift the squeegee before moving
backward to avoid damaging it.
If you do not wish to use the brush press the button
(Photo E-33) and the corresponding warning light will
turn off.
If you do not wish to use the suction press the button
(Photo E-34) and the corresponding warning light will
turn off.
6.13. WORK METHOD
6.13.1. PREPARATION AND WARNINGS
Remove any loose solid residue from the surface to be
treated (using suitable tools, such as vacuum clean-
ers, sweepers, etc.). It this is not done, the solid dirt
might prevent the squeegee from operating correctly,
reducing drying efficiency.
