3
The LMR 360R system offers accurate grade information for all visu-
al machine control applications, with 360° detection of any rotating
laser. The receiver attaches to the excavator arm with magnets, or
with clamps to a mast (optional).
It has two modes, fine and coarse, for deadband size (accuracy). In
coarse mode, there are 7 channels of information; in fine mode, 9
channels. These LED indicators show the position of the bucket or
blade in relation to the laser reference beam.
Built-in plumb indicator monitors angle of the stick, signaling if it’s
plumb or under- or over-extended. Vertical position ensures consistent
and accurate grade readings, saving money by reducing over- or
under-cutting.
LMD 360R Remote Display
Wireless RF technology links the remote in-cab display (LMD 360R)
to the receiver, eliminating a cable connection.
The remote mounts to the cab windshield, and won’t block the oper-
ator’s view. An in-cab display allows you to view the LED channel
indicators, the vertical indicator arrows, and the ditch and bucket in
the same view. It also allows you to position the receiver higher,
above the cab. This prevents the cab from blocking the laser signal
and ensures 360° reception.
The LMR 360R receiver is equipped with rechargeable battery
(NiMh type). A 110V/240V charger is included. Charging time is
12 hours. The battery LED is lit while charging and to indicate low
battery.
1. Description
2
1. Description 3
LMD 360R Remote Display
2. Power 3
3. Setup for excavating 4
4.1 LMR 360R with clamps
4.2 LMR 360R with magnets
4. Using the LMR 360R receiver 5
5. Using the LMD 360R remote display 6
6. Operation 6
7. Using the menu to change settings 7
8.1 Changing the settings using the remote display
8.2
Changing the settings in each menu position
8.3 Changing the settings using the receiver
8. Tr o u b l e s h o o t i n g 9
9. Radio frecuency interf e r e n c e 1 0
10. Specifications 1 1
11. Wa r r a n t y 1 2
Table of contents
2 . P o w e r
