BLOWER DATA CHP16/20
CHP16/20Ć024 BLOWER PERFORMANCE
230 VOLTS (With DownĆFlow Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 1385 655 1025 485 900 425 685 325
.05 12 1380 650 1035 490 915 430 700 330
.10 25 1365 645 1045 495 925 435 710 335
.15 37 1350 635 1045 495 930 440 715 335
.20 50 1330 630 1040 490 930 440 715 335
.25 62 1305 615 1030 485 925 435 715 335
.30 75 1275 600 1010 475 915 430 705 335
.40 100 1205 570 965 455 880 415 680 320
.50 125 1120 530 890 420 820 385 640 300
.60 150 1015 480 800 380 740 350 585 275
.70 175 900 425 685 325 640 300 510 240
.75 185 835 395 615 290 580 275 470 220
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP16/20Ć024 BLOWER PERFORMANCE
230 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 1435 675 1035 490 895 420 625 295
.05 12 1420 670 1050 495 915 430 645 305
.10 25 1400 660 1060 500 925 435 660 310
.15 37 1380 650 1060 500 935 440 670 315
.20 50 1360 640 1060 500 935 440 675 320
.25 62 1335 630 1050 495 930 440 675 320
.30 75 1305 615 1035 490 920 435 670 315
.40 100 1235 585 985 465 875 415 650 305
.50 125 1155 545 910 430 810 380 605 285
.60 150 1065 505 810 380 720 340 545 255
.70 175 960 455 690 325 605 285 465 220
.75 185 905 425 620 295 540 255 415 195
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP16/20Ć030 BLOWER PERFORMANCE
230 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 1485 700 1345 635 1115 525 920 435
.05 12 1480 700 1340 630 1120 530 930 440
.10 25 1465 690 1335 630 1120 530 940 445
.15 37 1455 685 1325 625 1115 525 945 445
.20 50 1435 675 1315 620 1110 525 945 445
.25 62 1420 670 1305 615 1105 520 940 445
.30 75 1400 660 1285 605 1095 515 935 440
.40 100 1350 635 1250 590 1065 505 910 430
.50 125 1295 610 1200 565 1025 485 875 415
.60 150 1230 580 1145 540 975 460 820 385
.70 175 1160 545 1075 505 915 430 755 355
.75 185 1120 530 1040 490 885 420 720 340
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP16/20Ć036 BLOWER PERFORMANCE
230 VOLTS (With DownĆFlow Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 1360 640 1270 600 1070 505 890 420
.05 12 1355 640 1250 590 1060 500 885 420
.10 25 1350 635 1230 580 1050 495 880 415
.15 37 1330 630 1220 575 1035 490 870 410
.20 50 1310 620 1210 570 1020 480 860 405
.25 62 1295 610 1190 560 1005 475 845 340
.30 75 1280 605 1170 550 990 470 830 390
.40 100 1230 580 1130 535 960 455 800 380
.50 125 1170 550 1070 505 910 430 760 360
.60 150 1100 520 990 465 850 400 700 330
.70 175 1020 480 890 420 780 370 620 295
.75 185 975 460 830 390 740 350 570 270
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP16/20Ć030 BLOWER PERFORMANCE
230 VOLTS (With DownĆFlow Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 1485 700 1250 590 1085 500 905 425
.05 12 1460 690 1250 590 1075 505 900 425
.10 25 1430 675 1240 585 1070 505 895 420
.15 37 1400 660 1235 585 1060 500 890 420
.20 50 1375 650 1225 580 1045 495 885 420
.25 62 1345 635 1215 575 1035 490 875 415
.30 75 1315 620 1200 565 1020 480 865 410
.40 100 1255 590 1165 550 990 465 835 395
.50 125 1190 560 1125 530 950 450 805 380
.60 150 1125 530 1075 510 910 430 770 365
.70 175 1060 500 1015 480 865 410 725 340
.75 185 1025 485 985 465 840 395 700 330
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
CHP16/20Ć036 BLOWER PERFORMANCE
230 VOLTS (With Horizontal Air Openings)
External Static
Air Volume at Various Blower Speeds
External Static
Pressure
High
MediumĆ
High
MediumĆ
Low
Low
in. w.g. Pa cfm L/s cfm L/s cfm L/s cfm L/s
0 0 1450 685 1370 645 1080 510 900 425
.05 12 1430 675 1350 635 1070 505 890 420
.10 25 1410 665 1330 630 1060 500 880 415
.15 37 1395 660 1310 615 1055 500 875 415
.20 50 1380 650 1290 610 1050 495 870 410
.25 62 1360 640 1270 600 1040 490 860 405
.30 75 1340 630 1250 590 1030 485 850 400
.40 100 1300 615 1210 570 1010 475 830 390
.50 125 1250 590 1170 550 970 460 810 380
.60 150 1200 565 1120 530 930 440 770 365
.70 175 1150 545 1060 500 890 420 710 335
.75 185 1125 530 1025 485 870 410 670 315
NOTE Ċ For 208v unit operation, derate air volume by 7% All air data is measured
external to the unit with dry coil and without air filter.
