ELECTRICAL DATA CHP16
ModelĂNo. Ć024 Ć030 Ć036 Ć048 Ć060
LineĂvoltageĂdataĂ-Ă60Ăhz 208/230v - 1 phase
208/230v
1 phase
208/230v
3 phase
460v -
3 phase
208/230v
1 phase
208/230v
3 phase
460v -
3 phase
208/230v
1 phase
208/230v
3 phase
460v -
3 phase
Recommended max. fuse size (amps) 25 30 40 30 15 50 35 15 60 40 20
{Minimum Circuit Ampacity 16 21 27 20 11 34 23 11 39 27 13
Compressor
Rated load amps 10.1 13.0 17.7 12.2 6.2 21.8 12.8 6.4 25.0 15.5 7.5
C
ompressor
Locked rotor amps 60.0 69.4 100.0 77.0 39.0 131.0 91.0 46.0 170.0 124.0 60.0
Outdoor Coil
FullĂloadĂamps 1.1 0.73 2.3 1.1 2.3 1.1
Outdoor
Coil
FanĂMotor
LockedĂrotorĂamps 2.2 1.3 4.4 2.0 4.4 2.0
Indoor Coil
FullĂloadĂamps 2.1 3.0 1.8 3.9 1.8 4.6 2.4
Indoor
Coil
Blower Motor
LockedĂrotorĂamps 4.2 6.2 4.4 8.3 4.4 10.0 3.8
{ReferĂtoĂNational or CanadianĂElectricalĂCodeĂmanualĂtoĂdetermineĂwire,ĂfuseĂandĂdisconnectĂsizeĂrequirements.
Where current does not exceed 100 amps, HACR type circuit breaker may be used in place of fuse (U.S. Only).
NOTEĂ-ĂExtremesĂofĂoperatingĂrangeĂareĂplusĂandĂminusĂ10%ĂofĂlineĂvoltage.
ELECTRICAL CHP20
Single Phase
CHP20 ModelĂNo. CHP20Ć024 CHP20Ć030 CHP20Ć036 CHP20Ć042 CHP20Ć048 CHP20Ć060
LineĂvoltageĂdata - 60 hz 208/230v
"RecommendedĂmaximumĂfuseĂsizeĂ(amps) 30 35 40 50 60 70
{MinimumĂCircuitĂAmpacity 19 22 25 32 36 44
Compressors
RatedĂloadĂamps 12.2 13.8 16.1 20.1 23.7 28.8
C
ompressors
LockedĂrotorĂamps 61.0 73.0 88.0 104.0 129.0 169.0
Outdoor Coil
FullĂloadĂamps 1.1 2.3 2.4
Outdoor
Coil
FanĂMotor
LockedĂrotorĂamps 2.2 4.4
Indoor Coil
Blower Motor
FullĂloadĂampsĂ 2.1 3.0 3.9 4.6
Bl
ower
M
otor
(1 phase)
LockedĂrotorĂampsĂ 4.2 6.2 8.3 10.0
{ReferĂtoĂNationalĂor Canadian ElectricalĂCodeĂmanualĂtoĂdetermineĂwire,ĂfuseĂandĂdisconnectĂsizeĂrequirements.
"WhereĂcurrentĂdoesĂnotĂexceedĂ100Ăamps,ĂHACRĂtypeĂcircuitĂbreakerĂmayĂbeĂusedĂinĂplaceĂofĂfuse.
NOTEĂĊĂExtremesĂofĂoperatingĂrangeĂareĂplusĂandĂminusĂ10%ĂofĂlineĂvoltage.
ELECTRICAL CHP20
Three Phase
CHP20 ModelĂNo. CHP20Ć036 CHP20Ć048 CHP20Ć060
LineĂvoltageĂdata - 60 hz - 3 phase 208/230v 460v 208/230v 460v 208/230v 460v
"RecommendedĂmaximumĂfuseĂsizeĂ(amps) 25 15 35 15 45 20
{MinimumĂCircuitĂAmpacity 17 10 24 13 29 15
Compressors
RatedĂloadĂamps 10.3 5.2 13.5 7.4 17.3 9
C
ompressors
LockedĂrotorĂamps 77 39 120 49.5 137 62
Outdoor Coil
FullĂloadĂamps 1.1 0.73 2.3 1.1 2.4 1.3
Outdoor
Coil
FanĂMotor
LockedĂrotorĂamps 2.2 1.3 4.4 2 4.4 2.0
Indoor Coil
FullĂloadĂampsĂ 3 1.8 3.9 1.8 4.6 2.4
Indoor
Coil
Blower Motor (1 phase)
LockedĂrotorĂampsĂ 6.2 4.4 8.3 4.4 10 3.8
{ReferĂtoĂNationalĂor Canadian ElectricalĂCodeĂmanualĂtoĂdetermineĂwire,ĂfuseĂandĂdisconnectĂsizeĂrequirements.
"WhereĂcurrentĂdoesĂnotĂexceedĂ100Ăamps,ĂHACRĂtypeĂcircuitĂbreakerĂmayĂbeĂusedĂinĂplaceĂofĂfuse.
NOTEĂĊĂExtremesĂofĂoperatingĂrangeĂareĂplusĂandĂminusĂ10%ĂofĂlineĂvoltage.
