This installation manual will help you obtain a
safe, efficient, dependable installation for your
appliance and vent system. Please read and
understand these instructions before begin-
ning your installation.
INTRODUCTION
The _DVR5 Series are sealed combustion, air
circulating, vented decorative gas appliances
designed for residential applications. These
appliances must be installed using the _DST5
vent system routed horizontally to the outside
atmosphere.
The -CM and -RM (millivolt) appliances are
designed to operate on natural or propane gas.
A millivolt gas contro! valve with piezo ignition
system provides safe, efficient operation. Ex-
ternal electrical power is required to operate
the optional blower if installed; electrical power
must be wired during appliance installation.
TYPICAL INSTALLATION
The -CE and -RE (electronic) appliances are
designed to operate on natural or propane gas.
An electronic direct spark ignition system pro-
vides safe, efficient operation. External electri-
cal power is required to operate these units.
These appliances comply with National Safety
Standards and are tested and listed by IAS
{Report No. 2970008) to ANSI 221.50 - 1996
(in Canada, CAN/CGA-2.22-M96 and CAN/CGA-
2.17-M91) as vented decorative gas appliances.
Installation must conform to local codes. in the
absence of local codes, installation must com-
ply with the current National Fuel Gas Code,
ANSI 2223.1. (In Canada, the current CAN-1
B149 installation code.) Electrical wiring must
comply with the National Electrical Code ANSI/
NFPA 70 - {latest edition). (In Canada, the
current CSA C22-1 Canadian Electrical Code.)
DO NOT ATTEMPT TO ALTER OR MODIFY
THE CONSTRUCTION OF THE APPLIANCE OR
ITS COMPONENTS. ANY MODIFICATION OR
ALTERATION MAY VOID THE WARRANTY,
CERTIFICATION AND LISTINGS OF THIS UNIT.
AG Ne
NG
Figure 7
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
