Page 20
TABLE 9– ELECTRIC HEAT DATA (1 PHASE) – CB30M–51 & CB30M–65
Blower Coil
Electric Heat kW,
Number of
Volts
kW
Btuh
Blower
{Minimum Circuit Ampacity
Number
& Shipping Weight
teps
nput
nput
nput
Amps
Circuit 1 Circuit 2 Circuit 3
b 208/230v–1 ph b
ECB29-5
208 3.8 12,800 2.4 26 – – – – – – – –
(28K31)
220 4.2 14,300 2.4 27 – – – – – – – –
-
(28K32)
230 4.6 15,700 2.4 28 – – – – – – – –
4 lbs. (2 kg)
240 5.0 17,100 2.4 29 – – – – – – – –
ECB29-8
208 6.0 20,500 2.4 39 – – – – – – – –
(28K33)
220 6.7 22,900 2.4 41 – – – – – – – –
-
(28K34)
230 7.3 25,100 2.4 43 – – – – – – – –
4 lbs. (2 kg)
240 8.0 27,300 2.4 45 – – – – – – – –
ECB29-10
208 7.5 25,600 2.4 48 – – – – – – – –
(28K35)
220 8.4 28,700 2.4 51 – – – – – – – –
-
(28K36)
230 9.2 31,400 2.4 53 – – – – – – – –
5 lbs. (2 kg)
240 10.0 34,100 2.4 55 – – – – – – – –
208 9.4 32,000 2.4 22 38 – – – –
CB30M-51
ECB29-12.5CB
220 10.5 35,800 2.4 23 40 – – – –
CB30U-51
.
10 lbs.
5 k
230 11.5 39,200 2.4 24 42 – – – –
240 12.5 42,600 2.4 25 43 – – – –
208 11.3 38,400 2.4 26 45 – – – –
ECB29-15CB
220 12.6 43,000 2.4 27 48 – – – –
10 lbs.
5 k
230 13.5 47,000 2.4 28 49 – – – –
240 15.0 51,200 2.4 29 52 – – – –
208 15.0 51,200 2.4 48 45 – – – –
ECB29-20CB
220 16.8 57,300 2.4 51 48 – – – –
14 lbs.
6 k
230 18.4 62,700 2.4 53 49 – – – –
240 20.0 68,200 2.4 55 52 – – – –
208 18.8 64,100 2.4 41 38 38
ECB29-25CB
220 21.0 71,700 2.4 43 40 40
18 lbs.
8 k
230 23.0 78,300 2.4 45 42 42
240 25.0 85,300 2.4 47 43 43
ECB29-5
208 3.8 12,800 3.9 28 – – – – – – – –
(28K31)
220 4.2 14,300 3.9 29 – – – – – – – –
-
(28K32)
230 4.6 15,700 3.9 30 – – – – – – – –
4 lbs. (2 kg)
240 5.0 17,100 3.9 31 – – – – – – – –
ECB29-8
208 6.0 20,500 3.9 41 – – – – – – – –
(28K33)
220 6.7 22,900 3.9 43 – – – – – – – –
-
(28K34)
230 7.3 25,100 3.9 45 – – – – – – – –
4 lbs. (2 kg)
240 8.0 27,300 3.9 47 – – – – – – – –
ECB29-10
208 7.5 25,600 3.9 50 – – – – – – – –
(28K35)
220 8.4 28,700 3.9 53 – – – – – – – –
-
(28K36)
230 9.2 31,400 3.9 55 – – – – – – – –
5 lbs. (2 kg)
240 10.0 34,100 3.9 57 – – – – – – – –
208 9.4 32,000 3.9 24 38 – – – –
ECB29-12.5CB
220 10.5 35,800 3.9 25 40 – – – –
.
10 lbs.
5 k
230 11.5 39,200 3.9 26 42 – – – –
CB30M-65
240 12.5 42,600 3.9 27 43 – – – –
CB30U-65
208 11.3 38,400 3.9 28 45 – – – –
ECB29-15CB
220 12.6 43,000 3.9 29 48 – – – –
10 lbs.
5 k
230 13.5 47,000 3.9 29 50 – – – –
240 15.0 51,200 3.9 31 52 – – – –
208 15.0 51,200 3.9 50 45 – – – –
ECB29-20CB
220 16.8 57,300 3.9 53 48 – – – –
14 lbs.
6 k
230 18.4 62,700 3.9 55 50 – – – –
240 20.0 68,200 3.9 57 52 – – – –
208 18.8 64,100 3.9 43 38 38
ECB29-25CB
220 21.0 71,700 3.9 45 40 40
18 lbs.
8 k
230 23.0 78,300 3.9 47 42 42
240 25.0 85,300 3.9 48 43 43
208 22.5 76,900 3.9 50 45 45
ECB29-30CB
220 25.2 86,000 3.9 53 48 48
19 lbs.
9 k
230 27.5 94,000 3.9 55 50 50
240 30.0 102,400 3.9 57 52 52
{Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements. Use wires suitable for at least 167°F (75_C).
Electric heater capacity only — does not include additional blower motor heat capacity.
Minimum circuit ampacity for blower motor only.
To Next Page
