BLOWER DATA – CB29M
CB29M-51 BLOWER PERFORMANCE (460v – 1 ph)
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2135 1010 960 1895 895 800 1695 800 680
.05 10 2110 995 945 1875 885 785 1675 790 675
.10 25 2080 980 935 1855 875 775 1660 785 665
.15 35 2055 970 920 1830 865 765 1640 775 655
.20 50 2025 955 910 1805 850 755 1620 765 645
.25 60 1995 940 895 1780 840 740 1595 755 640
.30 75 1965 930 885 1755 830 730 1575 740 630
.40 100 1905 900 860 1700 800 710 1525 720 610
.50 125 1840 870 835 1640 775 685 1470 695 590
.60 150 1770 835 810 1580 745 665 1415 670 575
.70 175 1700 805 785 1515 715 640 1355 640 555
.80 200 1630 770 760 1445 680 620 1295 610 535
.85 210 1595 750 745 1410 665 605 1260 595 525
NOTE — All air data is measured external to unit with air filter in place.
Electric heaters have no appreciable air resistance.
CB29M-65 BLOWER PERFORMANCE (208/230v)
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium–High Medium Medium–Low Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2245 1060 1080 2130 1005 930 2000 945 820 1800 850 695 1565 740 570
.05 10 2220 1045 1070 2105 995 920 1980 935 815 1780 840 690 1550 730 570
.10 25 2190 1035 1060 2080 985 915 1955 925 805 1760 830 680 1535 725 565
.15 35 2165 1020 1050 2055 970 905 1935 910 795 1735 820 670 1520 715 560
.20 50 2135 1005 1040 2030 960 895 1910 900 785 1715 810 665 1500 710 555
.25 60 2105 995 1030 2000 945 885 1880 890 780 1690 795 655 1480 700 550
.30 75 2070 980 1020 1970 930 875 1855 875 770 1665 785 645 1460 690 540
.40 100 2005 945 995 1910 900 855 1795 850 750 1610 760 630 1415 670 530
.50 125 1935 910 975 1845 870 830 1735 820 730 1555 735 610 1365 645 515
.60 150 1855 875 950 1775 835 810 1665 785 710 1495 705 595 1310 615 500
.70 175 1775 840 925 1695 800 785 1595 755 690 1430 675 580 1245 590 485
.80 200 1690 800 900 1615 765 755 1520 715 665 1365 645 560 1180 555 470
.90 225 1600 755 875 1530 725 730 1440 680 645 1290 610 545 1105 520 455
.95 235 1555 735 865 1490 700 715 1395 660 635 1255 590 535 1070 505 450
NOTE — All air data is measured external to unit with air filter in place.
Electric heaters have no appreciable air resistance.
CB29M-65 BLOWER PERFORMANCE (460v – 1 ph)
External Static
Air Volume and Motor Watts at Specific Blower Taps
Pressure
High Medium Low
in. w.g. Pa cfm L/s Watts cfm L/s Watts cfm L/s Watts
.00 0 2230 1055 1145 2050 965 925 1790 845 750
.05 10 2200 1040 1135 2030 955 915 1770 835 740
.10 25 2170 1025 1120 2005 945 910 1745 825 735
.15 35 2140 1010 1110 1980 935 900 1725 815 725
.20 50 2110 995 1095 1960 925 890 1705 805 715
.25 60 2080 980 1085 1930 910 880 1680 795 705
.30 75 2045 965 1075 1905 900 870 1655 780 695
.40 100 1980 935 1050 1845 870 845 1605 755 675
.50 125 1910 900 1025 1785 840 825 1550 730 660
.60 150 1835 865 1000 1715 810 800 1490 705 640
.70 175 1760 830 975 1645 775 775 1425 675 620
.80 200 1680 795 950 1565 740 745 1360 640 600
.90 225 1600 755 925 1485 700 720 1290 610 585
NOTE — All air data is measured external to unit with air filter in place.
Electric heaters have no appreciable air resistance.
